Fizzy 3
AED 10900
FREE MAINTENANCE
FOR PROFESSIONAL USE
Standard Features
- Delivers Chilled Sparkling, Chilled Still & Ambient Water
- Elegant Modern Design w/ Polished
- Stainless Steel Finish
- 3-Stage Advanced Filtration Process
- Eco-Friendly Alternative
Technical Features
| TYPE OF MACHINE | Countertop |
| MOST COMMON USE | Restaurant, Hospitality & Corporate Office |
| WATER FILTRATION SYSTEM | 3-Stage Filtration – Sediment, Chlorine, Taste, Odor (CTO), Lead & Cysts |
| CONFIGURATION OF THE MACHINE | Consists of 1 filtration assembly (NWFS) + 1 refrigeration/ carbonation unit (NWSB) |
| CO2 CYLINDER (not provided) | Sold separately – connected with a 1/4″ JG tubing and pressure regulator (included) to the refrigeration/ carbonation unit (NWSB) |
| MATERIAL | Stainless steel body (AISI 430) |
| MAXIMUM CHILL CAPACITY | 80 Liters per hour |
| MAXIMUM FLOW CAPACITY | 150 Liters per hour |
| AVG. TIME TO FILL A ONE LITER BOTTLE | 15 Sec. |
| STANDARD OPER’G WATER SUPPLY PRESSURE PSI (BAR)-REGULATED WITH A PRESSURE REGULATOR (INCLUDED) | 40 psi min. – 100 psi max. (2.75 – 6.9 bar) |
| ELECTRIC POWER CONSUMPTION (APPROXIMATE) | 240 Watts Normal Oper’g/6 Watts Idle (US) 340 Watts Carbonation Oper’g (US) 170 Watts Normal Oper’g/ 9 Watts Idle (INT’L) 290 Watts Carbonation Oper’g (INT’L) |
| ELECTRICAL (VOLTS/HERTZ/AMPS) | 110-120V / 60HZ / 6 AMPS (US) 220-230V / 50HZ / 2.5 AMPS (INT’L) |
| REFRIGERATION GAS | R134a |
| DIMENSIONS: | REFRIGERATION / CARBONATION UNIT (NWSB): | FILTRATION SYSTEM (NWFS): |
| DEPTH | 26.375″ (670mm) including drip tray | 6.0″ (152 mm) |
| WIDTH | 17.625″ (447 mm) | 16.4″ (417 mm) |
| HEIGHT | 20.0″ (508 mm) total height with faucets |
14.4″ (366 mm) |
| WEIGHT | 75 lbs (34 kg) | 18 lbs (8.2kg) |
